ALL-IN-ONE INVERTER & BATTERY SYSTEM

IMAX-ESS 3.6KW + 8KWH

✨ Core Features & Advantages

Multi-Battery Support

Compatible with both Lithium and Lead-acid batteries for flexible system configurations.

High PV Capacity

Supports up to 5kW solar input with a wide 40-450V MPPT voltage range.

Grid-Tie Capability

Supports feed-in to grid for excess solar power utilization.

Pure Sine Wave Output

Provides clean, stable power for sensitive electronics.

WiFi Monitoring

Built-in WiFi connectivity for remote system monitoring and control.

Lithium Battery Activation

Supports direct activation of lithium batteries for simplified setup.

📋 Specifications Parameter

Category / Item	ESS 3.6KW+8KWH
AC Input
Rated Input Voltage (VAC)	208 / 220 / 230 / 240; L + N + PE
Voltage Range (VAC)	90~280±3 (normal mode); 170~280±3 (UPS mode)
Frequency (Hz)	50 / 60 (Auto Adaptive)
AC Output
Rated Capacity (kW)	3.6
Surge Power (kVA)	5.7
Voltage (VAC)	208 / 220 / 230 / 240
Power Factor (PF)	1
Frequency	50/60Hz±0.1%
Switch Time (ms)	10
Wave Form	Pure Sine Wave
Overload Capacity (Battery Mode)	60s@102%~110%; 10s@110%~130%; 3s@130%~150% ; 0.2s@>150%;
Max. Efficiency (Battery Mode)	92.7%@24VDC
Charger (PV / AC)
Solar Charger Type	MPPT
Max PV input current / power	18A / 5000W
Operating Voltage Range (VDC)	40~450
Max PV Open Circuit Voltage (VDC)	500
Max PV Charge Current (A)	100
Max AC Charge Current (A)	100
Max. Charge Current (PV + AC) (A)	100
Battery
Nominal Battery Voltage (VDC)	25.6VDC
Rated Energy	8KWh(0.2C , 25°C)
Usable Energy(90%DOD)	7.2KWh
Max.Charge/Discharge Current	75A/150A
Operation Voltage Range	20Vdc ~ 29.2Vdc
Operation Temperature	-10°C ~ +50°C
Interface
Display	LCD
Communication	USB
Monitoring	WiFi
General Data
Ingress Protection	IP20
Operating Temperature	-10 °C ~ 50 °C
Relative Humidity	5% ~ 95% (Non-condensing)
Storage Temperature	-15 °C ~ 60 °C
Max. Operating Altitude	4000m (Derating above 1000m)
Dimension
L×W×H (product size, mm)	440246760mm
L×W×H (package size, mm)	520436890mm
Net Weight (NW Kg)	73kg
Weight (GW Kg)	86kg

🌍 Typical Application Scenarios

🏠

Residential Solar Storage

Self-consumption optimization and backup power for homes with solar panels.

🏢

Small Business Backup

Reliable power continuity for small offices, shops, and remote workplaces.

⛺

Off-Grid Systems

Complete energy independence for cabins, remote locations, and mobile applications.

⚡

Peak Shaving

Reduce energy costs by storing solar energy and using it during high tariff periods.

⚡ Electrical Topology & Working Modes

PV Input (40-450V)

AC Grid Input

MPPT Charger + Inverter + BMS

Battery Bank (Li-ion/Lead-acid)

AC Load Output

Grid Feed-In

Supports multiple working modes: Solar Charging, AC Charging, Battery Backup, and Grid-Tie with feed-in capability.

🛡️ Protection & Safety Features

⚡

Over-Voltage Protection

🔋

Under-Voltage Protection

🌡️

Over-Temperature Protection

💥

Short-Circuit Protection

🔌

Over-Current Protection

🔒

Reverse Polarity Protection

❓ Frequently Asked Questions

Q: Can this system work with both lithium and lead-acid batteries?

A: Yes, the ESS 3.6KW+8KWH supports both lithium and lead-acid batteries, offering flexibility in system design and upgrades.

Q: What is the maximum solar power input supported?

A: The system supports a maximum PV input of 5000W with a wide MPPT range of 40-450V, allowing for high-power solar arrays.

Q: Does it support grid feed-in?

A: Yes, the unit supports feed-in to grid, allowing you to sell excess solar power back to the utility grid when applicable.

Q: Can I monitor the system remotely?

A: Yes, built-in WiFi connectivity enables remote monitoring and control via a compatible mobile app or web interface.
