Description
Engineered for Next‑Generation Cells
The 125kW Modular PCS is purpose‑built for 314Ah large‑format lithium‑ion cells, supporting 48S and 52S liquid‑cooled battery clusters with a 600–1000V ultra‑wide DC voltage range.
SiC power devices deliver >99% peak efficiency and significantly lower losses compared to traditional IGBT designs. The four‑leg (four‑wire) topology enables 100% unbalanced load capability, making it ideal for commercial and industrial applications.
Where It Delivers Value
- 🏭 Commercial & Industrial energy storage
- 🔌 Microgrid systems & island grids
- ☀️ Solar + storage integration (PV + BESS)
- 🚗 EV charging infrastructure with V2G readiness
- ⚡ Peak shaving & demand charge management
Product Advantages
CE certified · DC positive/negative contactor + fuse · over‑voltage, over‑current, thermal & short‑circuit protection
SiC power devices · ≥99% peak efficiency · full‑load efficiency ≥98% · reduced losses for higher project ROI
DSP + CPLD digital control · millisecond grid response · seamless on‑grid / off‑grid transition
Modular parallel design · 600–1000V wide DC range · compatible with LFP, NMC & vanadium flow batteries
Technical Specifications
| Parameter | Specification |
|---|---|
| Rated Power | 125 kW |
| DC Voltage Range | 600 – 1000 Vdc (full load: 630–950 V) |
| Max DC Current | 198 A |
| AC Voltage (Grid) | 400 V (-15% ~ +15%) |
| Peak Efficiency | ≥ 99% |
| Full‑Load Efficiency | ≥ 98% |
| Operating Temperature | –30 °C ~ +60 °C (>50 °C derating) |
| Ingress Protection | IP20 |
| Noise Level | ≤ 75 dB |
| Topology | Three‑level · Four‑leg (four‑wire) |
| Power Devices | SiC (silicon carbide) |
| Communication | RS485 · CAN · Ethernet · dry contact |
| Parallel Capability | Yes (modular parallel) |
| Certification | CE · GB/T 42288 |
Application Areas
Electrical Topology & Energy Flow
125kW · SiC · Four‑leg
Protection & Safety
Maintenance & Service
- • Periodic visual inspection
- • Cooling fan & filter cleaning
- • Terminal torque check
- • Firmware version verification
- • LED / HMI fault code diagnosis
- • Communication status check
- • Grid voltage & frequency validation
- • Remote diagnostic support
- • Engineering consultation
- • Customization & integration
- • On‑site & remote assistance
- • Spare parts supply
