Description
The BIM75040-250K modular energy storage PCS converter is constructed with bidirectional high-frequency isolation ACDC modules, combining the advantages of high-frequency isolation and modularization. The cabinet can accommodate both AIM75040 and AIM300100 modules, and can be flexibly configured into different power levels and battery voltages according to requirements
Product Features:
- Safer and more reliable:
-
- Full high – frequency isolation design ensures safety between the battery and the grid/load;
-
- Friendly to the battery, battery packs are connected in parallel, reducing battery series – parallel connection, avoiding battery 环流 (circulating current) problems, and extending battery life;
-
- Compatible with battery packs of different manufacturers and different characteristics connected to the DC side of the module;
-
- Friendly to the grid, the AC sides are paralleled together, showing single – unit characteristics.
- More efficient:
-
- High – frequency isolation between the battery and the grid, eliminating the industrial frequency transformer, with higher high – frequency isolation efficiency, reaching more than 95%.
- More intelligent and friendly:
-
- Cooperating with the STS module, seamless switching between grid – connected and off – grid can be realized;
-
- Covers multiple battery voltage levels of passenger cars (40V ~ 750Vdc), with a wide battery voltage range.
- Lower cost:
-
- Compared with traditional modular energy storage, high – frequency isolation eliminates the industrial frequency transformer and indirect costs (cabinet, fan, etc.), and the system cost is low;
-
- Through a set of circuits, two functions of charging and inverting are realized, and charging and discharging are integrated, with low cost.
- More flexible configuration:
-
- Module hot – swap design, flexible system configuration;
-
- Flexibly configured into energy storage converters of different power levels and battery voltage levels according to requirements.
Product Specification Parameters:
| Specification Parameters | High-Frequency Isolated Energy Storage PCS |
|---|---|
| Charging Section | |
| AC Side Parameters | |
| Rated grid voltage | 400Vac (380/400/415Vac can be set) |
| Grid voltage range | 304Vac ~ 485Vac |
| Grid voltage frequency | 50/60±10% (50Hz/60Hz two modes are self-adaptive) |
| Voltage system | Three-phase four-wire (3W+PE) |
| Input current | ≤456A |
| Power factor | ≥0.99, full load |
| Current harmonic | <3%, full load |
| Battery Side Parameters | |
| Output voltage | 200 ~ 750VDC, rated 500VDC |
| Output rated current | 480A |
| Rated power | 250kw |
| Power derating | 95%max (using SiC devices), 94% (using Si devices) |
| Charging efficiency | 95%Max |
| Temperature accuracy | ±1% |
| Ripple factor | <1%Vo |
| Discharging Section | |
| Battery Side Parameters | |
| Battery voltage range | 200 ~ 750VDC |
| Discharging current | 480A Max |
| AC Side Parameters | |
| V2G (grid-connected discharging) | |
| Grid voltage range | 304Vac ~ 485Vac |
| Grid voltage frequency | 50/60±10% (50Hz/60Hz two modes are self-adaptive) |
| Output power | 250KW |
| Power derating | Grid voltage 304Vac~323Vac linear derating |
| Efficiency | 95%Max (using SiC devices), 94% (using Si devices) |
| Other Performance | |
| Protection Functions | |
| Overvoltage protection | Equipped |
| Overcurrent protection | Equipped |
| Short-circuit protection | Equipped |
| Over-temperature protection | Equipped |
| Other Parameters | |
| Working temperature | -30 ~ 65°C, output power derates above 55°C |
| Storage temperature | -40 ~ 75°C |
| Noise | <62dB |
| Dimensions (widthdepthheight) | 6008002000mm |
| Weight | 350kgs |
| Protection level | IP20 (whole machine) |
| Cooling method | Intelligent speed regulation, forced air cooling |
| Certification Standards | Performance/Safety/EMC GB/T34120-2017 Technical Specification for Energy Storage Converters in Electrochemical Energy Storage Systems |
