BIM1K070 300V15KW bidirectional V2G power module PCS energy storage converter

Function Description:

• More Secure and Reliable:
  • Full high-frequency isolation design ensures safety between the battery and the grid/load;
  • Full digital control with DSP+CPLD, multiple levels of software and hardware protection against overcurrent, overvoltage, and overtemperature, ensuring safety and reliability;
  • Dual DSP design for stable and reliable performance;
  • Reliable parallel operation capability, facilitating power expansion, allowing up to 12 modules to operate in parallel;
  • Strong grid adaptability.
• Higher Efficiency:
  • Compared to traditional bidirectional power supply solutions, the high-frequency isolation eliminates the need for a line-frequency transformer, achieving high-frequency isolation efficiency of over 95%;
  • AC/DC adopts three-level technology, with a maximum efficiency of 98%;
  • DC/DC adopts soft-switching resonant technology, with a maximum efficiency of 98%.
• More Intelligent and User-Friendly:
  • Compatible with STS modules, supporting seamless switching between grid-connected and off-grid modes;
  • Covers multiple battery voltage levels for passenger vehicles (100V~750Vdc), with a wide battery voltage range;
  • Wide grid voltage range and 50/60Hz voltage frequency adaptability;
• Lower Cost:
  • Compared to traditional bidirectional power supply solutions, high-frequency isolation eliminates the line-frequency isolation transformer, reducing system cost;
  • By using a single circuit to achieve both charging and inversion functions, integrating charging and discharging, the cost is reduced;
• More Flexible Configuration:
  • Smaller size and compact structure;
  • Modular hot-swappable design for flexible system configuration;

Product Specification Parameters:
