Description
Product Characteristics
🛡️ Excellent Safety Performance: “6 – layer” Safety Protection Ensures Zero Accidents
We equip the product with a “6 – layer” safety protection mechanism. Each layer serves as a strong shield. For instance, the over – charge and over – discharge protection for cells prevent abnormal energy storage. Thermal management and electrical safety protection for the battery system avoid potential risks. This comprehensive protection ensures zero accidents throughout the product’s lifecycle, providing users with reliable safety.
✅ Rigorous Testing and Certification: Pass Multiple Thermal Runaway and Safety Tests
We subject the product to numerous strict thermal runaway and safety tests at authoritative institutions. During these tests, the product faces extreme conditions such as high temperatures and short – circuits. Its excellent performance in passing all tests demonstrates high reliability. This not only proves the product’s quality but also gives users confidence in its safety during use.
🔄 Seamless Switching Capability: Unnoticeable Grid – connection and Disconnection Switching for Continuous Power Supply
The product boasts an outstanding seamless switching ability between grid – connected and off – grid modes. The switching process is almost imperceptible. In grid – connected mode, it can smoothly interact with the grid. When switching to off – grid mode, it quickly takes over to ensure uninterrupted power supply. This feature is crucial for places with high power stability requirements, like data centers and hospitals.
🏭 Multi – field Applicability: Suitable for Industrial and Commercial Energy Storage, Micro – grids, and Substation Area Energy Storage
This product has wide applicability. In industrial and commercial energy storage, it helps enterprises reduce electricity costs through peak – valley price arbitrage. In micro – grids, it works with renewable energy generation equipment to achieve energy self – sufficiency. For substation area energy storage, it solves problems like voltage fluctuations and improves power supply quality.
⚡ Enhanced Grid Regulation: Improve Flexibility and Regulation of Distribution Substation Areas
The product significantly enhances the flexibility and regulation of distribution substation areas. It can respond quickly to grid dispatching instructions. By storing and releasing energy as needed, it stabilizes the fluctuations of renewable energy generation. This improves the grid’s ability to absorb renewable energy and ensures stable grid operation.
💰 Significant Economic Benefits: One – time Investment, Enjoy Up to 20 – year Returns
Users can gain substantial economic benefits with a one – time investment. Through peak – valley price arbitrage, participation in power market transactions, and providing grid auxiliary services, the product brings considerable returns. Its long service life and low maintenance costs further reduce the total cost of ownership, offering users long – term and stable economic benefits.
💡 High – efficiency Integrated Design: Photovoltaic – storage Integration Reduces CAPEX and OPEX
The product adopts a high – efficiency integrated design, integrating photovoltaic and storage systems. This simplifies the system structure, reduces the floor space, and lowers the initial investment cost (CAPEX). At the same time, optimized operation management and intelligent control strategies improve energy conversion efficiency and reduce operating costs (OPEX), providing a more convenient and economical energy solution.
Imax100 – 215LP/125 – 261LP Energy Storage System: Parameter Details in Tabular Form
In the dynamic realm of energy storage, precise parameters are vital for assessing a system’s capabilities. The Imax100 – 215LP/125 – 261LP energy storage system boasts well – crafted parameters, offering reliable solutions across various applications. Below is a detailed presentation of its parameters in a table format.
| Parameter Category | Sub – parameter | Details and Explanations |
|---|---|---|
| DC Side Parameters | Specifications | Options: 100kW/215kWh and 125kW/261kWh. Cater to different energy storage capacity needs, from small – scale commercial backup to medium – sized industrial energy regulation. |
| Cell Type | LFP/280Ah and LFP/314Ah. Known for high safety, long cycle life, and stable performance, ensuring long – term stable system operation. | |
| Battery System Settings | Capacities: 215.04kWh and 261.248kWh; Configuration: 1P240S and 1P260S. Ensure full cell performance utilization, improving charge – discharge efficiency. | |
| Battery Voltage Range | 672V – 864Vdc and 728V – 949Vdc. Wide ranges adapt to different input/output conditions, enhancing flexibility. | |
| PV Parameters | Maximum Power | 20kW and 40kW. Effectively connect to different – scale PV systems, utilizing solar resources for efficient storage. |
| Maximum Voltage | 850V. Compatible with various PV modules, ensuring efficient PV power collection and transmission. | |
| Start – up Voltage | 325V. Allows prompt system start under suitable illumination for energy storage. | |
| MPPT Input Voltage Range | 260V – 720V. Maximizes tracking of PV array’s maximum power point under varying conditions, improving PV efficiency. | |
| Maximum Input Current | 60A and 60A + 60A (two – way). Meets current input needs of different – power PV systems for stable operation. | |
| AC Side (Grid – connected) Parameters | Output Power | 110kVA@40℃ 100kVA@45℃ and 125kVA. Enables stable power interaction with the grid, meeting grid – connected power demands. |
| Rated Current | 145A and 181A. Ensures stable current output during grid – connected operation. | |
| Rated Voltage Range | – 20% – 15%. Adapts to grid voltage fluctuations, ensuring stable grid connection. | |
| Frequency Range | 50Hz/47Hz – 52Hz; 60Hz/57Hz – 62Hz. Suitable for grids with different frequency standards. | |
| Harmonics | < 3% (above 30% load). Ensures high – quality output power, reducing interference. | |
| AC Side (Off – grid) Parameters | Rated Power | 100kVA and 125kVA. Provides stable power support in off – grid states for remote areas, emergency backup, etc. |
| Rated Current | 145A and 181A. Ensures stable power supply during off – grid operation. | |
| Rated Voltage | 400V/230V. Meets common off – grid load voltage requirements. | |
| Output Voltage Harmonics | < 1.5% (resistive load). Ensures high – quality off – grid output for various loads. | |
| Frequency Range | 50Hz/60Hz. Provides appropriate frequency according to load needs. | |
| Output Overload (Current) | 1.25/100s, >1.25/300ms. Handles short – term load surges, ensuring stable operation. | |
| System Parameters | Operation Mode | Supports off – grid operation, ideal for areas without grid or with high power independence needs. |
| System Efficiency | > 89% (@25±2℃, PCS: 98.5% maximum). High – efficiency conversion reduces energy loss. | |
| Power Factor | Adjustable between – 1 – 1. Users can optimize power quality and reduce reactive power loss. | |
| Cooling Method | Active liquid – cooling. Controls system temperature, ensuring stable operation in various environments. | |
| Allowable Operating Temperature Range | Charging: 0 – 55℃; Discharging: – 20 – 55℃. Adapts to different climates, expanding application scope. | |
| System Cycle Times | > 6000 times (@25±2℃, 0.5P, SOH > 80%). Long cycle life reduces costs and provides long – term service. | |
| Altitude | ≤2000m (derating above 2000m). Has wide geographical applicability. | |
| Weight | 2200kg and 2620kg. Reasonable weight facilitates transportation and installation. | |
| External Communication | Ethernet and wireless 4G. Enables remote monitoring and management, improving O&M efficiency. | |
| Protection/Anti – corrosion Level | IP54/C3. Prevents dust and water ingress, adapts to harsh environments, and has anti – corrosion ability. | |
| Fire – fighting System | Perfluorohexanone (PACK – level) + PACK – level detection + single PACK protection. Provides comprehensive safety protection. | |
| External Electrical Interface | 3L + N + PE. Facilitates connection with external equipment. | |
| Cabinet Size | (WDH): 1220mm1500mm2000mm. Compact design saves space for easy installation. |
The Imax100 – 215LP/125 – 261LP energy storage system, with its comprehensive parameters, is a strong contender in the energy storage field. It offers efficient, stable, and safe solutions for both grid – connected and off – grid applications, driving energy transformation and sustainable development.
