Description
Product Characteristics
🔒 Strong Proactive Safety Protection
Early – fault cell positioning warnings ensure stability. By promptly detecting potential cell abnormalities, it proactively prevents safety hazards and maintains system stability.
🛡️ Comprehensive 3D Protection System
Provides full – scale protection for equipment, assets, and personnel. This multi – dimensional protection minimizes risks and ensures worry – free operation in all aspects.
⚖️ Stable Isolation and Reliable Operation
Features isolation transformers to ensure dependable operation. Isolation transformers effectively isolate electrical interference, guaranteeing stable and reliable system performance.
🧩 High – Efficiency Integrated Design
One – piece design integrates key equipment. This design approach improves overall system efficiency and facilitates equipment management.
📱 Digital Energy Management
Digital methods achieve efficient management. Through digital control, it optimizes energy allocation and utilization, enhancing overall energy management efficiency.
🌈 Flexible Application Scenarios
Suitable for scenarios like optical storage micro – grids. Its versatility allows it to adapt to various energy storage needs in different settings.
💰 Excellent Economic Efficiency
Peak shaving and other measures reduce costs. By optimizing power usage patterns, it delivers good economic returns through cost reduction.
Imax1125 – 2170L: In-depth Parameter Analysis
DC – side Parameters
Cell Type
Utilizes LFP314Ah cells. LFP (Lithium Iron Phosphate) cells offer high safety, long cycle – life, and stable electrochemical performance, forming a reliable energy storage foundation.
Specifications
Rated at 1125kW/2170kWh. This power – energy combination is designed to meet the demands of large – scale energy storage applications, providing substantial power output and ample energy capacity.
Battery System Configuration
Configured as 2170.3kWh/9P240S. This configuration optimizes the battery pack’s performance, ensuring efficient energy storage and discharge.
System Rated Voltage
The system rated voltage is 768Vdc, which is suitable for high – power energy storage systems and facilitates integration with power conversion equipment.
Voltage Range
The DC voltage range is 672 – 864Vdc. This wide range allows for flexible charging and discharging under various operating conditions.
AC – side Parameters
AC Rated Power
The AC rated power is 1125kW (125kW * 9). It can effectively support the power needs of industrial and commercial applications.
AC Maximum Power
The AC maximum power is 1237kW, providing short – term over – power capabilities to handle sudden peak loads.
AC Current Distortion Rate
The AC current distortion rate is ≤3%, ensuring high – quality power output and reducing interference with other electrical equipment.
DC Component
The DC component is 100% (specific meaning depends on system parameters, indicating a certain operating state).
Grid Rated Voltage
The grid rated voltage is 400Vac/3P + N + PE, a common industrial power supply standard.
Power Factor Adjustable Range
The power factor adjustable range is -1 ~ 1, allowing for flexible adjustment to match grid requirements and improve power quality.
Rated Grid Frequency
The rated grid frequency is 50Hz/60Hz, making it compatible with different grid frequencies around the world.
System Parameters
Maximum System Efficiency
The maximum system efficiency is ≥88%, reducing energy losses during energy conversion and improving overall system performance.
Charge – Discharge Rate
The charge – discharge rate is 0.5P, which helps protect the battery cells and prolongs their service life.
Discharge Depth
The discharge depth is 95%, maximizing the utilization of stored energy in the battery.
Cycle Times
The cycle times are ≥8000 times, indicating a long service life and good cost – effectiveness.
Communication Interface
The communication interface supports Ethernet/RS485, facilitating easy integration with monitoring and control systems for remote management.
Protection Level
The protection level is IP55, providing effective protection against dust and water ingress, ensuring reliable operation in various environments.
Cooling Method
The cooling method combines liquid cooling and forced air cooling. This approach maintains optimal operating temperatures for different components.
Operating Temperature Range
The operating temperature range is -25°C ~ 55°C, allowing the system to operate in diverse climatic conditions.
Relative Humidity
The relative humidity range is 5 – 95%RH, with no condensation, suitable for various humidity environments.
Noise Level
The noise level is ≤80dB, minimizing noise pollution in the operating area.
Altitude
The system can operate at altitudes ≤2000m (derating above 2000m), suitable for different geographical locations.
Fire – fighting System
Features a fire – fighting system with gas sol (at PACK – level and cluster – level) and water fire – fighting. This multi – layered fire protection ensures high safety.
Dimensions (WidthDepthHeight)
The dimensions are 605824382591(mm), designed for easy installation in available spaces.
Weight
The weight is 25t, manageable for transportation and installation with proper equipment.
Compliance Standards
Complies with UN3536, UN38.3, IEC62619, UL9540A, UL1973 standards, ensuring product quality, safety, and reliability.
