Description
The IM100-20KF series high-frequency switching rectifier module is an AC-DC module with adjustable AC voltage input and DC voltage output. It features high power density, high power factor, low harmonics and high efficiency, and has the performance of multi-module parallel connection.
- Soft-start resonator
- Source PFC technology
- DSP digital control
- Protected by multiple patents
Product Features:
- High Efficiency:
Reduces energy consumption and loss, complies with energy-saving and emission-reduction requirements, and saves electricity costs for customers.
- High Power Density:
Saves customer space and reduces system costs.
- DSP Digital Control:
Fewer components, higher environmental stability, higher reliability, and more convenient expansion.
- Low Input Harmonics:
Reduces pollution to the power grid and improves grid adaptability.
- Wide Input Voltage Range, Wide Output Voltage Range:
Suitable for the vast majority of different input and output voltage scenarios.
- Wide Operating Temperature Range:
The wide operating temperature range meets most harsh working environments.
- Comprehensive Fault Self-Detection and Warning:
Rich fault detection for easy customer maintenance.
● Product Specification Parameters:
| Specification Parameters | IM100-20KF | IM120-20KF | IM200-20KF |
|---|---|---|---|
| DC Output | |||
| Rated Output Power | 20kW | ||
| Rated Output Current | 200A | 100A | |
| Auxiliary Power Supply Output | Module startup state: 12V5A Module shutdown state: 12V2A | ||
| Output Voltage Range | 30VDC-100VDC | 30VDC-120VDC | 60V-200V |
| Current-Limiting Adjustable Range | 10% – 110% steplessly adjustable | ||
| Peak-to-Peak Noise | ≤1% | ||
| Telephone Harmonic Noise | No requirement | ||
| Voltage Stabilization Accuracy | ≤±0.5% | ||
| Current Stabilization Accuracy | ≤±1% | ||
| Average Current | ≤±5% | ||
| Efficiency | ≥95% | ||
| AC Input | |||
| Rated Input Voltage | Three-phase 380Vac/480Vac | ||
| Input Voltage Range | 323Vac – 520Vac (full load), 323Vac – 260Vac (linear reduction to half load) | ||
| Input Current | <40A | ||
| Frequency | 45Hz – 65Hz | ||
| Power Factor (PF) | ≥0.99 | ||
| Total Harmonic Distortion (THD) of Current | ≤5% | ||
| Input Protection | Fuse; Lightning protection circuit | ||
| Working Environment Conditions | |||
| Working Environment Temperature | -40°C – 50°C (operation) 50°C – 70°C (shutdown) | ||
| Storage Temperature | -40°C – 70°C | ||
| Relative Humidity | 0 – 95% | ||
| Altitude | 2000m full-load output |
| Product Safety and Reliability | |
|---|---|
| Insulation Strength | The input to the machine case can withstand 50Hz effective value 2500VAC or equivalent 3535VDC for 1 minute; The input to the output can withstand 50Hz effective value 3000VAC or equivalent 4242VDC for 1 minute. |
| MTBF | >120000 hours |
| External Dimensions and Weight | |
| External Dimensions | 289 (width) × 84 (height) × 389 (depth) |
| Module Net Weight | 9.5Kg |
| Communication and Alarms | |
| Communication Interface | CAN |
| Maximum Parallel Number | 60 |
| Output Positive and Negative Overcurrent Protection | Alarms and status are reported and monitored through the CAN communication port, as well as indicated by three panel LED lights. |
